Specification Port Connector Size Ø28 mm Fibre Type PMMA / Glass Material Black Hard Anodized Aluminium Mains Supply Voltage 120-277V / 50-60Hz Total Power Consumption 80 W LED Power Consumption 75 W LED Lifetime (L80) > 60,000 hours LED Driver Lifetime > 100,000hours (@ Tc 70°C at 80% load) Dimmer System (0/1-10V, DMX, DALI/DALI-2, D4i, PWM, and Casambi upon request) Thermal Protection Automatic resettable Protection Rating IP68 (External LED Driver rated IP67) Cooling System Natural Convection Ambient Temperature -10°C to 45°C Applied LED Nichia CCT (Nominal) 4000K CRI (Ra) Typical Value ≥ 93 Weight 6 kg
FL 1300 XT268S 4000K CRI 90+
High-Performance, Waterproof Lighting Solution for Outdoor and Fiber Optic Applications
The FL 1300 XT268S is a high-performance, IP68-rated light generator designed for demanding outdoor and flood-prone environments. Compatible with PMMA and glass fibre optic lighting, it delivers flicker-free illumination with a high Colour Rendering Index (CRI) for superior light quality and long-term reliability.
The FL 1300 XT268S provides a wide range of dimming control options, supporting 0/1-10V, PWM, DMX, DALI/DALI-2, D4i, Casambi, and Potentiometer-based control systems, ensuring seamless integration into diverse lighting configurations. It is available in multiple colour temperatures, including Warm, Neutral, Cool White, Tunable White, and RGBW, with custom configurations available upon request to accommodate specific project requirements.
Designed for wall-mounted installation, the FL 1300 XT268S supports up to 30 meters of cable and remote driver connection. Withstanding water pressure up to 10 meters, ensures durability, making it ideal for professional applications requiring high-quality, adaptable lighting.
