Specification Port Connector Size Ø28 mm Fibre Type PMMA / Glass Material Black Hard Anodized Aluminium Mains Supply Voltage 100-277V / 50-60Hz Total Power Consumption 110 W LED Power Consumption 100 W LED Lifetime (L80) > 60,000 hours LED Driver Lifetime > 100,000 hours (at 80% load and Tc 70°C) Dimmer System DMX (Casambi available upon request) Thermal Protection Automatic resettable Protection Rating IP20 (External LED Driver rated IP66 / IP67) Cooling System Active Fan Cooling Cooling system lifetime 70,000 hours at 40°C Fan Noise Level ≤ 30 dB Ambient Temperature -10°C to 45°C Applied LED Nichia CCT (Nominal) 3000K CRI (Ra) Typical Value ≥ 93 Weight 5.1 kg
FL 1500 C DMX Dim 3000K CRI 90+
High-Power Performance Light Generator with High Lumen Output for Indoor and Fiber Optic Applications
The FL 1500 C DMX Dim series is a premium, high-power performance light generator engineered for indoor environments and dry locations. Its high-lumen output offers exceptional performance. Designed for compatibility with PMMA and glass fiber optic lighting, it provides precise and reliable illumination for a wide range of applications. The FL 1500 C DMX Dim offers smooth dimming functionality with DMX, ensuring enhanced flexibility and seamless control.
This advanced light generator ensures flicker-free performance and a high Colour Rendering Index (CRI), providing superior light quality and stability for optimal visual comfort. It is available in various colour temperatures, including Warm, Neutral, and Cool White, with custom configurations available upon request to accommodate specific project requirements.
With an optional wall-mounted installation kit, the FL 1500 C DMX Dim Series offers a versatile and energy-efficient solution for demanding lighting projects, making it the perfect choice for professional environments.
| Title | Item | |
|---|---|---|
|
CTC filter -1000K Ø28 | 01261019 |
|
CTC filter -1200K Ø28 | 01261020 |
|
CTC filter -900K Ø28 | 01261021 |
|
CTC filter +2000K Ø28 | 01261022 |
|
CTC filter +1000K Ø28 | 01261023 |
|
DMX Controller | 01600302 |
|
FL 1500 XT filter holder | 49001530 |
|
Adaptor Ø28/Ø9 | 78000130 |
|
DMX cable 1 to 50 m from control unit | 99030060 |
|
DMX line termination, XLR male | 99030065 |
|
DMX cable 5 m for XT-2 | 99030062 |
|
DMX cable 2.5 m for XT-2 | 99030061 |
|
DMX cable 10 m XLR plug for XT-2 serie | 99030063 |
|
DMX cable 11 to 50 m XLR plugs | 99030058 |
|
DMX cable 11 to 50 m for XT-2 | 99030064 |
|
DMX kabel 51-100 m XLR stik | 99030059 |
|
DMX cable 10 m XLR plugs | 99030057 |
|
DMX cable 2.5 m XLR plugs | 99030056 |
|
DMX cable per metre | 99030055 |
|
DMX cable 5 m XLR plugs | 99030052 |
|
DMX 512 splitter | 01600310 |
|
Casambi to DMX Controller | 80000031 |
