FL 1500 XT C DMX Dual 4000K CRI 90+

Item no.
Categories:

High-Power Light Generator with Advanced Colour & Twinkle Wheel Effects for Fiber Optic Lighting
The FL 1500 XT series is a premium high-power light generator engineered for outdoor environments. Its enhanced high-lumen output offers exceptional performance. Designed for compatibility with PMMA and glass fiber optic lighting, it provides precise and reliable illumination for a wide range of applications. The FL 1500 XT offers smooth dimming functionality with a range of control options, including 0/1-10V, PWM, DMX, DALI/DALI-2, D4i, Casambi, and Potentiometer, ensuring enhanced flexibility and seamless control.

This advanced light generator ensures flicker-free performance and a high Colour Rendering Index (CRI), providing superior light quality and stability for optimal visual comfort. It is available in various colour temperatures, including Warm, Neutral, Cool White, Tunable White, and RGBW, with custom configurations available upon request to accommodate specific project requirements. The FL 1300 XT offers options with a controllable 6-color and/or twinkle wheel, delivering dynamic and customizable lighting effects for creative interior applications.

With a wall-mounted installation, the FL 1500 XT Series offers a versatile and energy-efficient solution for demanding lighting projects, making it the perfect choice for professional environments.

Specification
Port Connector SizeØ28 mm
Fibre TypePMMA / Glass
MaterialBlack Hard Anodized Aluminium
Mains Supply Voltage100-240V / 50-60Hz
Total Power Consumption115 W
LED Power Consumption100 W
LED Lifetime (L80)> 60,000 hours
LED Driver Lifetime> 100,000 hours (at 80% load and Tc 70°C)
Dimmer SystemDMX (Casambi available)
Thermal ProtectionAutomatic resettable
Protection RatingIP45
Cooling SystemActive Fan Cooling
Cooling system lifetime70,000 hours at 40°C
Fan Noise Level≤ 33 dB
Ambient Temperature-10°C to 45°C
Applied LEDNichia
CCT (Nominal)4000K
CRI (Ra) Typical Value≥ 93
Weight                                                                 8.6 kg

Show all
Title Item
CTC filter -1000K Ø28 01261019
CTC filter -1200K Ø28 01261020
CTC filter -900K Ø28 01261021
CTC filter +2000K Ø28 01261022
CTC filter +1000K Ø28 01261023
FL 1500 XT filter holder 49001530
Adaptor Ø28/Ø9 78000130
DMX line termination, XLR male 99030065
DMX Controller 01600302
DMX cable 2.5 m for XT-2 99030061
DMX cable 11 to 50 m for XT-2 99030064
DMX cable 10 m XLR plugs 99030057
DMX cable 1 to 50 m from control unit 99030060
DMX cable 10 m XLR plug for XT-2 serie 99030063
DMX cable 5 m for XT-2 99030062
DMX kabel 51-100 m XLR stik 99030059
DMX cable 11 to 50 m XLR plugs 99030058
DMX cable 5 m XLR plugs 99030052
DMX cable 2.5 m XLR plugs 99030056
DMX cable per metre 99030055
DMX 512 splitter 01600310
Casambi to DMX Controller 80000031
Title Item
Fan replacement kit 01308000
