Specification Port Connector Size Ø28 mm Fibre Type PMMA / Glass Material Black Hard Anodized Aluminium Mains Supply Voltage 100-277V / 50-60Hz Total Power Consumption 115 W LED Power Consumption 100 W LED Lifetime (L80) > 60,000 hours LED Driver Lifetime > 100,000 hours (at 80% load and Tc 70°C) Dimmer System DMX (Casambi available upon request) Thermal Protection Automatic resettable Protection Rating IP20 (External LED Driver rated IP66 / IP67) Cooling System Active Fan Cooling Cooling system lifetime 70,000 hours at 40°C Fan Noise Level ≤ 33 dB Ambient Temperature -10°C to 45°C Applied LED Nichia CCT (Nominal) 3000K CRI (Ra) Typical Value ≥ 93 Weight 7.6 kg
FL 1500 C DMX Twinkle 3000K CRI 90+
High-Power Light Generator with Advanced Colour & Twinkle Wheel Effects for Fiber Optic Lighting
The FL 1500 C DMX series is a high-performance DMX/RDM-controllable light generator, specifically designed for indoor environments and dry locations. For seamless wireless control, a Casambi-enabled option is available upon request. Engineered for exceptional lumen output, it delivers superior illumination and reliability. Optimized for compatibility with PMMA and glass fibre optic lighting systems, it ensures precise and consistent lighting for a wide range of applications.
This advanced light generator ensures flicker-free performance and a high Colour Rendering Index (CRI), providing superior light quality and stability for optimal visual comfort. It is available in various colour temperatures, including Warm, Neutral, and Cool White, with custom options available, to meet diverse lighting needs. The FL 1500 C DMX features a controllable 6-colour wheel and/or twinkle wheel, delivering dynamic and customizable lighting effects for creative interior applications.
With an optional wall-mounted installation kit, the FL 1500 C DMX Series offers a versatile and energy-efficient solution for demanding lighting projects, making it the perfect choice for professional environments.
| Title | Item | |
|---|---|---|
|
CTC filter -1000K Ø28 | 01261019 |
|
CTC filter -1200K Ø28 | 01261020 |
|
CTC filter -900K Ø28 | 01261021 |
|
CTC filter +2000K Ø28 | 01261022 |
|
CTC filter +1000K Ø28 | 01261023 |
|
Mounting Kit FL 1500 C | 01369001 |
|
DMX Controller | 01600302 |
|
FL 1500 XT filter holder | 49001530 |
|
Adaptor Ø28/Ø9 | 78000130 |
|
DMX line termination, XLR male | 99030065 |
|
DMX cable 11 to 50 m XLR plugs | 99030058 |
|
DMX cable 11 to 50 m for XT-2 | 99030064 |
|
DMX cable 10 m XLR plug for XT-2 serie | 99030063 |
|
DMX kabel 51-100 m XLR stik | 99030059 |
|
DMX cable 2.5 m for XT-2 | 99030061 |
|
DMX cable 1 to 50 m from control unit | 99030060 |
|
DMX cable 10 m XLR plugs | 99030057 |
|
DMX cable 5 m for XT-2 | 99030062 |
|
DMX cable per metre | 99030055 |
|
DMX cable 2.5 m XLR plugs | 99030056 |
|
DMX cable 5 m XLR plugs | 99030052 |
|
DMX 512 splitter | 01600310 |
|
Casambi to DMX Controller | 80000031 |
