Specification Port Connector Size Ø28 mm Fibre Type PMMA / Glass Material Black Hard Anodized Aluminium Mains Supply Voltage 100-277V / 50-60Hz Total Power Consumption 110 W LED Power Consumption 100 W LED Lifetime (L80) > 60,000 hours LED Driver Lifetime > 100,000 hours (at 80% load and Tc 70°C) Dimmer System 0/1-10V (DMX, DALI/DALI-2, D4i, PWM, Pot., and Casambi available upon request) Thermal Protection Automatic resettable Protection Rating IP20 (External LED Driver rated IP66 / IP67) Cooling System Active Fan Cooling Cooling system lifetime 70,000 hours at 40°C Fan Noise Level ≤ 30 dB Ambient Temperature -10°C to 45°C Applied LED Nichia CCT (Nominal) 4000K CRI (Ra) Typical Value ≥ 93 Weight 5.1 kg
FL 1500 B-2 4000K CRI 90+
High-Power Performance Light Generator with High Lumen Output for Indoor and Fiber Optic Applications
The FL 1500 B-2 series is a premium, high-power performance light generator engineered for indoor environments and dry locations. Its high-lumen output offers exceptional performance. Designed for compatibility with PMMA and glass fiber optic lighting, it provides precise and reliable illumination for a wide range of applications. The FL 1500 B-2 offers smooth dimming functionality with a range of control options, including 0/1-10V, PWM, DMX, DALI/DALI-2, D4i, Casambi, and Potentiometer, ensuring enhanced flexibility and seamless control.
This advanced light generator ensures flicker-free performance and a high Colour Rendering Index (CRI), providing superior light quality and stability for optimal visual comfort. It is available in various colour temperatures, including Warm, Neutral, and Cool White, with custom configurations available upon request to accommodate specific project requirements.
With an optional wall-mounted installation kit, the FL 1500 B-2 Series offers a versatile and energy-efficient solution for demanding lighting projects, making it the perfect choice for professional environments.
